One brand, two naming systems
Craftsman's tool box series, decoded: S1000, S2000, 3000 Series and V-Series
The series numbers are tier labels, not load ratings, and the line most people search for is sold in one store only. Here is what each one publishes.
Craftsman sells three metal storage tiers you can order online - S1000, S2000 and V-Series - and they are separated by far more than their names suggest: 24 gauge steel and a 300 lb rating at the bottom, 16-18 gauge and 3,000 lb at the top. The 3000 Series most people search for was announced in 2018, reached stores in 2019 and is sold through Lowe's - no Amazon listing carries it.
Two naming systems, running at the same time
In August 2018 Craftsman announced its metal storage as the 1000S, 2000S and 3000S Series, and Lowe's shelves those boxes as 1000 Series, 2000 Series and 3000 Series to this day. Craftsman's own site names the same tiers S1000 and S2000, and in June 2023 it added a third name above both: V-Series. One brand, two vocabularies, and search results that mix them freely.
The collision is not just retail shorthand either. Craftsman launched a 2000S Series in November 2018, then announced a "refreshed S2000 series" in December 2021 that it described as reengineered from the ground up while keeping the iconic design. Both are real, both are Craftsman, and a listing that offers you nothing but the words 2000 Series does not tell you which one is in the box.
What each line actually publishes
| Line | Body steel | Per drawer | Overall load | Casters | Warranty | Where you can buy it |
|---|---|---|---|---|---|---|
| S1000 | 24 ga | 30 lb | 300 lb | 3 x 1 in | 3-year limited | Amazon and Lowe's |
| S2000 | 18-20 ga I-frame | 100 lb | 1,500 lb | 5 x 2 in, toe-lock | Not published on the pages we checked | Amazon and Lowe's |
| 3000 Series | 18 ga I-frame (review figure) | 120-200 lb (review figure) | 3,000 lb | 6 x 2 in | 10-year (review figure) | Lowe's only |
| V-Series | 16-18 ga I-frame | Up to 200 lb | Up to 3,000 lb | 6 x 2 in, suspension | 10-year limited | Amazon and Lowe's |
Published figures from Craftsman product pages and press releases. The 3000 Series cells marked review figure come from a 2019 hands-on review of CMST26380RB - Craftsman's own release publishes only that line's depth, overall capacity and casters.
The 3000 Series is a Lowe's line
Searching Amazon's catalog for this page returned no 3000 Series product at all - only S1000, S2000 and V-Series boxes. If you specifically want a 3000 Series chest, you are shopping in one store, and this site earns nothing from telling you so. If what you actually want is the 3,000 lb rating and the 6 in casters that define the line, the V-Series publishes both and can be delivered.
And Kobalt sells a 3000 Series too
Worth knowing before you walk into the store: Lowe's sells a Kobalt 3000 Series 41-inch cabinet as well, and it is a different box from a different brand. It publishes 41 in W x 24.5 in D x 37.5 in H, over 17,000 cubic inches and a 2,000 lb capacity, with no steel gauge at all. Two 3000 Series cabinets, one aisle, and only one of them tells you what it is made of - Kobalt vs Craftsman puts the two side by side.
The number is a tier, not a load rating
It is a natural reading that 1000, 2000 and 3000 are pound figures. They are not. Craftsman's own launch release gives the 1000S a maximum capacity of 300 pounds - less than a third of what the name implies. Only the 3000S happens to match its number.
- 1000S / S1000: 300 lb overall, 30 lb per drawer, 3 in x 1 in casters
- 2000S / S2000: 1,500 lb overall, 100 lb per drawer, 5 in x 2 in casters
- 3000S / 3000 Series: 3,000 lb overall, 22 in deep, 6 in x 2 in casters
- V-Series: up to 3,000 lb overall, up to 200 lb per drawer, 6 in x 2 in suspension casters
Read as a ladder rather than a scale, it is a steep one. The step from S1000 to S2000 multiplies the overall rating by five and the per-drawer rating by more than three. The step up to V-Series doubles both again. Three names that look like small increments describe boxes an order of magnitude apart, which is why cross-shopping on price alone goes wrong here.
The volume gap nobody puts in a table
Craftsman publishes a cubic-inch figure for the S1000 combo - 1,227 - and for the S2000 boxes, at 14,014. That is a factor of eleven between two lines whose names differ by a single digit, and it is the number that actually decides whether your tools fit. Neither price nor gauge tells you that.
Then the disclosure stops. On the V-Series, the most expensive metal storage Craftsman sells, there is no published cubic-inch figure, no published height and no published empty weight. The comparison a buyer most wants at the top of the range - am I getting more room, or only stronger drawers? - is the one the maker does not enable. Drawer capacity, explained covers how to estimate it yourself from depth and drawer count.
Which line you should actually buy
Pick the tier by what the drawers will carry, not by the badge. Hand tools and a cordless kit sit comfortably inside the S1000's numbers. Full socket sets, breaker bars and impact guns do not, and that is the line where the S2000 stops being an upgrade and starts being the minimum.
Quick picks
Ranked on published specifications, not on hype. The key number is the figure that decides each pick, quoted from the maker. Tap a row for the full write-up, or go straight to the listing.
| # | Product | Best for | Key number | Price |
|---|---|---|---|---|
| 1 |  Craftsman S1000 26 in. comboThe entry line, and the only Craftsman box here whose gauge is printed as a single number rather than a range. That candor cuts both ways: 24 gauge is the thinnest steel Craftsman puts in a metal storage line, and the whole two-piece combo is rated 300 lb. | The bottom rung of the Craftsman ladder | 24 gabody steel | $288.00 · Check on Amazon |
| 2 |  Craftsman S2000 41 in. cabinetThe direct answer to Kobalt's 41-inch cabinet, and the only one of the two that can be shipped to you. Craftsman publishes an 18-20 gauge I-frame where Kobalt publishes no gauge at all - but at 18 in deep against Kobalt's 24.5, it gives up about 3,000 cubic inches to do it. | The 41-inch cabinet you can actually have delivered | 18-20 gasteel I-frame | $968.45 · Check on Amazon |
| 3 | CraftsmanNo photo Craftsman S2000 52 in. chestCraftsman publishes an 18-20 gauge I-frame rather than a single figure, which is a real answer and an annoying one: the frame is thicker than the panels. At 16 in deep it is the shallow option here, which is a virtue in a narrow garage and a limit everywhere else. | A shallow bay where 22 inches of depth will not fit | 16 indepth | Check price on Amazon |
| 4 |  Craftsman V-Series 41 in. cabinetThe top of the current ladder, and the published numbers justify most of the jump: 16-18 gauge I-frame against the S2000's 18-20, drawers rated to 200 lb against 100, and 3,000 lb overall against 1,500. What Craftsman will not publish is a height, a weight or a cubic-inch figure. | The professional end of the same brand | 3,000 lboverall rating | $1,553.00 · Check on Amazon |
Every key number is a figure the manufacturer publishes. Where a maker publishes none, the row says so rather than substituting an estimate of ours.
Top pick · The bottom rung of the Craftsman ladder
Craftsman S1000 26 in. 5-Drawer Rolling Tool Chest Combo (CMST82763BK)
The entry line, and the only Craftsman box here whose gauge is printed as a single number rather than a range. That candor cuts both ways: 24 gauge is the thinnest steel Craftsman puts in a metal storage line, and the whole two-piece combo is rated 300 lb.
- Body steel
- 24 ga0.0239 in (0.61 mm)
- Per drawer
- 30 lb24 lb working
- Storage
- 0.7 cu ft1,227 cu in
- Empty weight
- Not published
What works
- Publishes a single gauge figure where the dearer Craftsman lines publish a range
- Publishes cubic inches, a per-drawer rating and an overall rating, so it can be compared rather than guessed at
- Made in the USA with global materials, like the rest of Craftsman's metal storage
- Cheap enough to be a second box rather than the box
What does not
- 24 gauge is the thinnest steel of any Craftsman metal storage line
- 30 lb per drawer, against 100 lb on the S2000 and up to 200 lb on the V-Series
- 1,227 cu in is roughly a twelfth of what the S2000 52 in. chest holds
- Craftsman publishes no dimensions and no empty weight on its own page
| Published specification | |
|---|---|
| Body steel | 24 gauge steel construction |
| Drawers | 5, full-extension ball-bearing slides |
| Per-drawer rating | 30 lb |
| Total load rating | 300 lb for the combo |
| Storage volume | 1,227 cu in (about 0.7 cu ft) |
| Casters | 3 in x 1 in (Craftsman's product page and its launch release describe the swivel and lock split differently) |
| Lock | Keyed locking system |
| Warranty | 3-year limited |
| Origin | Made in the USA with global materials |
| Dimensions | Not published by Craftsman |
| Empty weight | Not published by Craftsman |
| Where it is sold | Amazon, plus other retailers |
Who it is for
A first box, a spare for a shed or a second bay, or anyone who wants Craftsman's cheapest metal drawers rather than its best ones.
What it is not for
Impact guns, full socket sets, or any load approaching the 300 lb the combo is rated for.
2 · The 41-inch cabinet you can actually have delivered
Craftsman S2000 Series 41 in. 10-Drawer Rolling Tool Cabinet (CMST341102BK)
The direct answer to Kobalt's 41-inch cabinet, and the only one of the two that can be shipped to you. Craftsman publishes an 18-20 gauge I-frame where Kobalt publishes no gauge at all - but at 18 in deep against Kobalt's 24.5, it gives up about 3,000 cubic inches to do it.
- Body steel
- 18 ga0.0478 in (1.21 mm)
- Per drawer
- 100 lb80 lb working
- Storage
- 8.1 cu ft14,014 cu in
- Empty weight
- Not published
What works
- Publishes a gauge at all, which the Kobalt cabinet it competes with does not
- The I-frame range is more honest than a single figure - it says the frame is thicker than the panels
- 1,500 lb across 10 soft-close drawers rated 100 lb each, with the arithmetic adding up
- Genuinely buyable online, where the Lowe's house brands in this size class are not
What does not
- 18 in deep will not take a long breaker bar or a 24 in torque wrench lying flat
- About 3,000 cubic inches behind the same-width Kobalt, which is entirely the depth difference
- Craftsman publishes no empty weight and no dimensions on its own page
- Amazon stock on the 41-inch cabinets is thin and moves in and out
| Published specification | |
|---|---|
| Body steel | 18-20 gauge steel I-frame construction |
| Dimensions | 41 in W x 18 in D x 37-1/2 in H (retail listing; Craftsman publishes no dimensions) |
| Drawers | 10, soft-close |
| Per-drawer rating | 100 lb |
| Total load rating | 1,500 lb |
| Storage volume | 14,014 cu in |
| Casters | 5 in x 2 in, toe-locking brakes, reinforced mounting |
| Lock | Internal locking system with over-molded key |
| Included | Cabinet drawer trays and a magnetic paper towel holder |
| Empty weight | Not published |
| Where it is sold | Amazon, plus other retailers |
Who it is for
A narrow garage where 24 in of cabinet depth would stop the car door, and where delivery matters.
What it is not for
Long tools laid flat, or anyone who can get to a Lowe's and wants the deeper box.
3 · A shallow bay where 22 inches of depth will not fit
Craftsman S2000 Series 52 in. 8-Drawer Tool Chest (CMST98272)
Craftsman publishes an 18-20 gauge I-frame rather than a single figure, which is a real answer and an annoying one: the frame is thicker than the panels. At 16 in deep it is the shallow option here, which is a virtue in a narrow garage and a limit everywhere else.
- Body steel
- 18 ga0.0478 in (1.21 mm)
- Per drawer
- 100 lb80 lb working
- Storage
- 8.1 cu ft14,014 cu in
- Empty weight
- Not published
What works
- 16 in deep fits a bay where a 22 in box would block the car door
- Publishes a storage volume, which makes it comparable rather than adjectival
- The I-frame spec is honest about mixed gauges instead of quoting the thickest panel
What does not
- 16 in of depth means long tools sit diagonally or not at all
- 18-20 ga is a range, so the thin end is what the panels actually are
- Top chest only - this is not a floor-standing box
| Published specification | |
|---|---|
| Body steel | 18-20 gauge steel I-frame construction (as published) |
| Dimensions | 51.5 in W x 16 in D x 24.5 in H |
| Drawers | 8 |
| Per-drawer rating | 100 lb |
| Storage volume | 14,014 cu in (about 8.1 cu ft) |
| Power | Integrated power strip with USB |
| Where it is sold | Amazon, plus other retailers |
Who it is for
A narrow garage, a bench top, or a second chest for shallow hand tools.
What it is not for
Torque wrenches and breaker bars, which need depth this box does not have.
Sources for this entry
4 · The professional end of the same brand
Craftsman V-Series 41 in. 11-Drawer Rolling Tool Cabinet (CMSTVS4111BK)
The top of the current ladder, and the published numbers justify most of the jump: 16-18 gauge I-frame against the S2000's 18-20, drawers rated to 200 lb against 100, and 3,000 lb overall against 1,500. What Craftsman will not publish is a height, a weight or a cubic-inch figure.
- Body steel
- 16 ga0.0598 in (1.52 mm)
- Per drawer
- 200 lb160 lb working
- Storage
- Not published
- Empty weight
- Not published
What works
- 16-18 gauge I-frame is the thickest steel Craftsman publishes on any storage line
- 200 lb drawers and a 3,000 lb overall rating, both published on Craftsman's own page
- 10-year limited warranty, against 3 years on the S1000
- Suspension-loaded 6 in x 2 in casters, which is the real answer to rolling a loaded box over a cracked slab
What does not
- No published height, empty weight or cubic-inch figure on the dearest box Craftsman sells
- 21 in deep needs the floor space, and 41 in of width does not buy the volume a 52 in box would
- Amazon stock on V-Series cabinets is thin and moves in and out
- Several times the price of the S2000 cabinet in the same 41 in width
| Published specification | |
|---|---|
| Body steel | 16-18 gauge steel I-frame construction |
| Dimensions | 41 in W x 21 in D; Craftsman publishes no height |
| Drawers | 11, full-extension soft-close ball-bearing |
| Per-drawer rating | Up to 200 lb |
| Total load rating | Up to 3,000 lb |
| Casters | 6 in x 2 in, suspension-loaded |
| Power | Integrated 6-outlet power strip with 2 USB ports |
| Lock | Tubular locking system |
| Warranty | 10-year limited |
| Origin | Made in the USA with global materials, Sedalia, Missouri |
| Storage volume | Not published |
| Empty weight | Not published |
| Where it is sold | Amazon, plus other retailers |
Who it is for
A daily professional box whose drawers carry impact guns and full socket sets, where a 10-year warranty is worth paying for.
What it is not for
A home garage that the S2000 would serve just as well for a fraction of the money.
How we picked
- What does Craftsman itself publish? Every figure in the table below comes from a Craftsman product page or a Craftsman press release. Where only a third-party review publishes a number, the cell says so rather than passing it off as a maker specification.
- Can you actually order it? A line sold through a single retailer is one most online buyers cannot compare, price or return easily. That is marked in its own column, not buried in the prose.
- Does the name tell you the specification? Where two Craftsman names cover the same tier, we give the model number, because the name alone does not settle which generation you are looking at.
- Gauge, drawer rating and overall rating together. Any one of the three on its own flatters a box. A thick body with 30 lb slides is still a 30 lb box.
What we did not do
Everyone in this category says they spent seventy-five hours testing tool chests. We have not opened any of these boxes, and we say so. What we do instead: compile the published specs, convert the steel gauges, multiply out the slide ratings, cite the maker’s own listing, and show the arithmetic so you can check it. The full method, including how to challenge a figure.
If you searched for the 3000 Series
- Decide whether you want the name or the numbers. The 3,000 lb rating, the deep body and the 6 in x 2 in casters that define the line are all on the V-Series as well, and that one ships.
- If you want the name specifically, budget a trip to Lowe's rather than a delivery date. There is no online route to it we can find, affiliate or otherwise.
- Buying used, search the model rather than the series. CMST26380RB is the 63 in. eight-drawer cabinet, measured at 21,034 cubic inches in a 2019 hands-on review - a figure Craftsman never published itself.
- If your real question was width rather than line, 56-inch tool boxes and 46-inch tool boxes compare across every brand, not just this one.
Where Craftsman sits against the other names
Craftsman's real advantage in this category is mundane and worth a lot: it is one of the few well-documented names you can have delivered. Its closest rivals by price are store exclusives. Kobalt vs Craftsman is the Lowe's-aisle comparison, Husky vs Craftsman is the Home Depot one, and tool box brands maps which names you can order at all.
Common questions
Is the Craftsman 3000 Series discontinued?
We cannot confirm that either way and will not guess. Lowe's blocks automated page requests, so we could not verify current stock for this page. What we can confirm: Amazon's catalog carries no 3000 Series box, and Craftsman's current lineup is named S1000, S2000 and V-Series. Treat the 3000 Series as a line to check locally rather than one to order.
What is the difference between the Craftsman 2000 Series and the S2000?
Craftsman launched a 2000S Series in November 2018 and announced a refreshed S2000 series in December 2021, describing it as reengineered from the ground up. The current line publishes 18-20 gauge I-frame construction, 100 lb drawers, a 1,500 lb overall rating and casters with toe-locking brakes. If a listing gives you only the words 2000 Series and no model number, you cannot tell which generation it is.
What gauge steel is a Craftsman tool box?
There is no single answer, which is the point of this page: 24 gauge on the S1000, 18-20 gauge I-frame on the S2000, 16-18 gauge I-frame on the V-Series. A review that says Craftsman is thin, or that Craftsman is solid, is describing one line and implying all of them. Steel gauge, explained covers what the numbers mean and why lower is thicker.
Are Craftsman tool boxes made in the USA?
Craftsman states "Made in the USA with global materials" on the S1000, on the 2018 launch lineup and on the V-Series, and names Sedalia, Missouri as the plant. That phrase means assembly in the USA from a mix of domestic and imported material. It is a real distinction in this category, and it is not the same claim as all-domestic.
Is the V-Series worth several times the price of the S2000?
On published numbers it doubles the per-drawer rating to 200 lb, doubles the overall rating to 3,000 lb, moves from 18-20 gauge to 16-18, and carries a 10-year warranty instead of the S1000's three. For a box that gets loaded and rolled every working day, that is a coherent set of upgrades. For a home garage that opens its drawers at weekends, the S2000 does the same job for a fraction of the money.
Sources
- Craftsman - S1000 26 in. 5-drawer rolling tool chest combo specification (CMST82763BK)
- Craftsman - S2000 Series 41 in. 10-drawer rolling tool cabinet specification (CMST98270RB)
- Craftsman - S2000 Series 52 in. 8-drawer tool chest specification (CMST98272RB)
- Craftsman - V-Series 41 in. 11-drawer steel rolling tool cabinet specification (CMSTVS4111BK)
- Craftsman press release - storage lineup launch, 1000S/2000S/3000S figures (16 August 2018)
- Craftsman press release - redesigned S2000 Series metal storage (2 December 2021)
- Stanley Black & Decker newsroom - CRAFTSMAN expands V-Series to metal tool storage (20 June 2023)
- Tools In Action - Craftsman 3000 Series tool chest review, CMST26380RB gauge and volume (4 March 2019)
Read next
The best tool box brands, and the ones you cannot actually buy online
Which tool box brands publish real specifications, which are store exclusives you cannot order, and why the badge matters less than the model number.
Kobalt vs Craftsman tool chest: same width, 6.5 inches apart
Two 41-inch cabinets on the same Lowe's shop floor, separated by 6.5 inches of depth and by which one publishes a steel gauge.
Husky vs Craftsman tool chests: both available, both published
The one brand matchup where both sides are actually available, so the published specs get to decide it.
Tool box steel gauge, converted into something you can use
Every gauge used in tool storage converted to inches and millimeters, why the numbers run backwards, and what thicker steel actually buys.
The best tool chests, ranked on what the maker actually publishes
The flagship roundup: chests and cabinets ranked on published gauge, slide ratings and volume, with three things we would actively skip.
