The whole table
Tool chests compared, on the numbers their makers actually publish
Twenty-two chests, four specifications, one table. Six models publish all four figures. Five publish none of them - and two of those five cost over a thousand dollars.
Of the 22 tool chests, cabinets and combo sets on this site, six publish all four of the numbers that decide a chest - steel gauge, per-drawer slide rating, total capacity and storage volume. The best-documented chest you can buy online today is the Milwaukee 46 in. 8-drawer cabinet: 20 gauge, 100 lb per drawer pair, 1,800 lb total, 15,160 cu in. Eleven of the 22 publish no steel gauge at all, and five publish nothing whatsoever.
Why there is no single winner row
People arriving at a comparison table usually want the bottom line highlighted. This one does not have one, and the reason is the point of the page: the chests are not all answering the same question, and more importantly they are not all answering with the same amount of information.
A 16-gauge chest with a 200 lb drawer rating is not simply better than a 20-gauge one with 100 lb - it is heavier, more expensive, and aimed at a different buyer. But a chest that publishes 16 gauge and 200 lb IS better documented than one that publishes neither, and that is a comparison that can be made fairly. So this table ranks on how much a maker is willing to tell you, and then lets you choose within that.
The six that publish all four numbers
| Model | Width | Drawers | Gauge | Per drawer | Total capacity | Volume |
|---|---|---|---|---|---|---|
| Husky 56 in. 18-drawer combo | 56 in | 18 | 19 ga | 120 lb | 3,000 lb | 42,876 cu in |
| Milwaukee 46 in. High Capacity cabinet | 46 in | 10 | 18 ga | 100 lb | 2,500 lb | 19,440 cu in |
| Milwaukee 46 in. 8-drawer cabinet | 46 in | 8 | 20 ga | 100 lb | 1,800 lb | 15,160 cu in |
| Craftsman S2000 41 in. cabinet | 41 in | 10 | 18 ga | 100 lb | 1,500 lb | 14,014 cu in |
| Milwaukee 46 in. top chest | 46 in | 8 | 18 ga | 100 lb | 1,000 lb | 15,877 cu in |
| Craftsman S1000 26 in. combo | 26 in | 5 | 24 ga | 30 lb | 300 lb | 1,227 cu in |
Every chest on this site that publishes steel gauge, per-drawer slide rating, total capacity AND storage volume. Figures are the makers' own, cited on each product's page.
Two things in that table are worth sitting with. The first is that Milwaukee's 46-inch cabinet publishes a THINNER gauge than its own top chest - 20 against 18 - which is the opposite of what most buyers assume, and the Milwaukee 46-inch review works through why. The second is the Craftsman S1000 row: 24 gauge, 30 lb drawers, 300 lb total. It is in this table because Craftsman publishes all four numbers honestly, and those numbers tell you plainly that it is a different class of product.
What this table does not contain
There is no score column, no star rating and no 'our rating' here, and there never will be. We have not opened any of these boxes and a number we invented would sit in the same column as numbers the makers published, which would make the published ones worth less. Every figure above is the maker's own, cited on the product's page. Our methodology sets out what we do instead of testing.
Quick picks
Ranked on published specifications, not on hype. The key number is the figure that decides each pick, quoted from the maker. Tap a row for the full write-up, or go straight to the listing.
| # | Product | Best for | Key number | Price |
|---|---|---|---|---|
| 1 |  Milwaukee 46 in. 8-drawer cabinetMilwaukee's standard 46-inch cabinet, not a High Capacity unit - and the distinction is worth 1,800 lb against 2,500, 20 gauge against 18, and 18 inches of depth against 22. It is the one of the two that reliably has an Amazon listing. | The 46-inch cabinet that is actually on Amazon | 1,800 lbpublished capacity | $2,600.00 · Check on Amazon |
| 2 |  Craftsman V-Series 41 in. cabinetThe top of the current ladder, and the published numbers justify most of the jump: 16-18 gauge I-frame against the S2000's 18-20, drawers rated to 200 lb against 100, and 3,000 lb overall against 1,500. What Craftsman will not publish is a height, a weight or a cubic-inch figure. | The professional end of the same brand | 3,000 lboverall rating | $1,553.00 · Check on Amazon |
| 3 |  Craftsman S2000 41 in. cabinetThe direct answer to Kobalt's 41-inch cabinet, and the only one of the two that can be shipped to you. Craftsman publishes an 18-20 gauge I-frame where Kobalt publishes no gauge at all - but at 18 in deep against Kobalt's 24.5, it gives up about 3,000 cubic inches to do it. | The 41-inch cabinet you can actually have delivered | 18-20 gasteel I-frame | $968.45 · Check on Amazon |
| 4 |  56 in. 10-drawer cabinetPublishes 150 lb soft-close slides and a 3,000 lb-plus total across 23,583 cubic inches, but no body gauge - which is the single most useful number in the category and its absence is worth weighing. | Volume per dollar at 56 inches | 23,583 cu instorage volume | $2,200.00 · Check on Amazon |
| 5 |  Craftsman S1000 26 in. comboThe entry line, and the only Craftsman box here whose gauge is printed as a single number rather than a range. That candor cuts both ways: 24 gauge is the thinnest steel Craftsman puts in a metal storage line, and the whole two-piece combo is rated 300 lb. | The bottom rung of the Craftsman ladder | 24 gabody steel | $288.00 · Check on Amazon |
Every key number is a figure the manufacturer publishes. Where a maker publishes none, the row says so rather than substituting an estimate of ours.
Top pick · The 46-inch cabinet that is actually on Amazon
Milwaukee 46 in. 8-Drawer Rolling Steel Storage Cabinet (48-22-8520)
Milwaukee's standard 46-inch cabinet, not a High Capacity unit - and the distinction is worth 1,800 lb against 2,500, 20 gauge against 18, and 18 inches of depth against 22. It is the one of the two that reliably has an Amazon listing.
- Body steel
- 20 ga0.0359 in (0.91 mm)
- Per drawer
- 100 lb80 lb working
- Storage
- 8.8 cu ft15,160 cu in
- Empty weight
- Not published
What works
- 1,800 lb published total capacity, which is a real figure and a good one at this width
- Angle iron reinforced frame and 5 in industrial casters, both published by Milwaukee
- Pre-cut drawer liners included, which is a genuine cost most makers push onto you
- 46 in fits a single-car bay that a 56 in box does not
What does not
- 20 gauge is 0.0359 in - the budget-default thickness, and thinner than the 18 ga High Capacity line people assume they are buying
- 18 in deep, four inches shallower than the High Capacity cabinet, so long tools sit diagonally
- Milwaukee does not publish a gauge for this model on its own page; the 20 ga figure comes from the retail listing
- 100 lb drawers rather than the 120-150 lb the wider cabinets publish
| Published specification | |
|---|---|
| Model | 48-22-8520, the standard 46 in line |
| Body steel | 20 gauge, per the Amazon listing; Milwaukee does not publish a gauge for this model |
| Dimensions | 46 in W x 18 in D |
| Drawers | 8 - four small, three medium, one large |
| Per-drawer rating | 100 lb soft close |
| Total capacity | 1,800 lb |
| Storage volume | 15,160 cu in (about 8.8 cu ft) |
| Casters | 5 in industrial, fixed and swivel, with a push handle |
| Frame | Angle iron reinforced |
| Locking | Barrel key internal locking system |
| Included | Premium pre-cut drawer liners, built-in power center |
| Where it is sold | Amazon, plus other retailers |
Who it is for
A 46-inch bay, hand tools rather than breaker bars, and a preference for buying online.
What it is not for
Anyone who wanted the 18-gauge Milwaukee. That is the High Capacity 48-22-8542, and it is a different box.
2 · The professional end of the same brand
Craftsman V-Series 41 in. 11-Drawer Rolling Tool Cabinet (CMSTVS4111BK)
The top of the current ladder, and the published numbers justify most of the jump: 16-18 gauge I-frame against the S2000's 18-20, drawers rated to 200 lb against 100, and 3,000 lb overall against 1,500. What Craftsman will not publish is a height, a weight or a cubic-inch figure.
- Body steel
- 16 ga0.0598 in (1.52 mm)
- Per drawer
- 200 lb160 lb working
- Storage
- Not published
- Empty weight
- Not published
What works
- 16-18 gauge I-frame is the thickest steel Craftsman publishes on any storage line
- 200 lb drawers and a 3,000 lb overall rating, both published on Craftsman's own page
- 10-year limited warranty, against 3 years on the S1000
- Suspension-loaded 6 in x 2 in casters, which is the real answer to rolling a loaded box over a cracked slab
What does not
- No published height, empty weight or cubic-inch figure on the dearest box Craftsman sells
- 21 in deep needs the floor space, and 41 in of width does not buy the volume a 52 in box would
- Amazon stock on V-Series cabinets is thin and moves in and out
- Several times the price of the S2000 cabinet in the same 41 in width
| Published specification | |
|---|---|
| Body steel | 16-18 gauge steel I-frame construction |
| Dimensions | 41 in W x 21 in D; Craftsman publishes no height |
| Drawers | 11, full-extension soft-close ball-bearing |
| Per-drawer rating | Up to 200 lb |
| Total load rating | Up to 3,000 lb |
| Casters | 6 in x 2 in, suspension-loaded |
| Power | Integrated 6-outlet power strip with 2 USB ports |
| Lock | Tubular locking system |
| Warranty | 10-year limited |
| Origin | Made in the USA with global materials, Sedalia, Missouri |
| Storage volume | Not published |
| Empty weight | Not published |
| Where it is sold | Amazon, plus other retailers |
Who it is for
A daily professional box whose drawers carry impact guns and full socket sets, where a 10-year warranty is worth paying for.
What it is not for
A home garage that the S2000 would serve just as well for a fraction of the money.
3 · The 41-inch cabinet you can actually have delivered
Craftsman S2000 Series 41 in. 10-Drawer Rolling Tool Cabinet (CMST341102BK)
The direct answer to Kobalt's 41-inch cabinet, and the only one of the two that can be shipped to you. Craftsman publishes an 18-20 gauge I-frame where Kobalt publishes no gauge at all - but at 18 in deep against Kobalt's 24.5, it gives up about 3,000 cubic inches to do it.
- Body steel
- 18 ga0.0478 in (1.21 mm)
- Per drawer
- 100 lb80 lb working
- Storage
- 8.1 cu ft14,014 cu in
- Empty weight
- Not published
What works
- Publishes a gauge at all, which the Kobalt cabinet it competes with does not
- The I-frame range is more honest than a single figure - it says the frame is thicker than the panels
- 1,500 lb across 10 soft-close drawers rated 100 lb each, with the arithmetic adding up
- Genuinely buyable online, where the Lowe's house brands in this size class are not
What does not
- 18 in deep will not take a long breaker bar or a 24 in torque wrench lying flat
- About 3,000 cubic inches behind the same-width Kobalt, which is entirely the depth difference
- Craftsman publishes no empty weight and no dimensions on its own page
- Amazon stock on the 41-inch cabinets is thin and moves in and out
| Published specification | |
|---|---|
| Body steel | 18-20 gauge steel I-frame construction |
| Dimensions | 41 in W x 18 in D x 37-1/2 in H (retail listing; Craftsman publishes no dimensions) |
| Drawers | 10, soft-close |
| Per-drawer rating | 100 lb |
| Total load rating | 1,500 lb |
| Storage volume | 14,014 cu in |
| Casters | 5 in x 2 in, toe-locking brakes, reinforced mounting |
| Lock | Internal locking system with over-molded key |
| Included | Cabinet drawer trays and a magnetic paper towel holder |
| Empty weight | Not published |
| Where it is sold | Amazon, plus other retailers |
Who it is for
A narrow garage where 24 in of cabinet depth would stop the car door, and where delivery matters.
What it is not for
Long tools laid flat, or anyone who can get to a Lowe's and wants the deeper box.
4 · Volume per dollar at 56 inches
High-Capacity 56 in. 10-Drawer Rolling Tool Cabinet
Publishes 150 lb soft-close slides and a 3,000 lb-plus total across 23,583 cubic inches, but no body gauge - which is the single most useful number in the category and its absence is worth weighing.
- Body steel
- Not published
- Per drawer
- 150 lb120 lb working
- Storage
- 13.6 cu ft23,583 cu in
- Empty weight
- Not published
What works
- 150 lb slides match the best published figure among these cabinets
- 13.6 cubic feet is a lot of drawer for the footprint
- Soft close throughout rather than on selected drawers
What does not
- No published body gauge - you are trusting the drawer rating alone
- No published empty weight, so the loaded-caster check cannot be done
- Amazon-native brand with limited service history behind it
| Published specification | |
|---|---|
| Body steel | Not published |
| Width | 56 in |
| Drawers | 10 |
| Per-drawer rating | 150 lb soft-close ball bearing |
| Total capacity | 3,000 lb and up |
| Storage volume | 23,583 cu in (about 13.6 cu ft) |
| Where it is sold | Amazon, plus other retailers |
Who it is for
A buyer optimizing drawer volume per dollar who accepts an unpublished gauge.
What it is not for
Anyone who wants to check the steel before they buy.
Sources for this entry
5 · The bottom rung of the Craftsman ladder
Craftsman S1000 26 in. 5-Drawer Rolling Tool Chest Combo (CMST82763BK)
The entry line, and the only Craftsman box here whose gauge is printed as a single number rather than a range. That candor cuts both ways: 24 gauge is the thinnest steel Craftsman puts in a metal storage line, and the whole two-piece combo is rated 300 lb.
- Body steel
- 24 ga0.0239 in (0.61 mm)
- Per drawer
- 30 lb24 lb working
- Storage
- 0.7 cu ft1,227 cu in
- Empty weight
- Not published
What works
- Publishes a single gauge figure where the dearer Craftsman lines publish a range
- Publishes cubic inches, a per-drawer rating and an overall rating, so it can be compared rather than guessed at
- Made in the USA with global materials, like the rest of Craftsman's metal storage
- Cheap enough to be a second box rather than the box
What does not
- 24 gauge is the thinnest steel of any Craftsman metal storage line
- 30 lb per drawer, against 100 lb on the S2000 and up to 200 lb on the V-Series
- 1,227 cu in is roughly a twelfth of what the S2000 52 in. chest holds
- Craftsman publishes no dimensions and no empty weight on its own page
| Published specification | |
|---|---|
| Body steel | 24 gauge steel construction |
| Drawers | 5, full-extension ball-bearing slides |
| Per-drawer rating | 30 lb |
| Total load rating | 300 lb for the combo |
| Storage volume | 1,227 cu in (about 0.7 cu ft) |
| Casters | 3 in x 1 in (Craftsman's product page and its launch release describe the swivel and lock split differently) |
| Lock | Keyed locking system |
| Warranty | 3-year limited |
| Origin | Made in the USA with global materials |
| Dimensions | Not published by Craftsman |
| Empty weight | Not published by Craftsman |
| Where it is sold | Amazon, plus other retailers |
Who it is for
A first box, a spare for a shed or a second bay, or anyone who wants Craftsman's cheapest metal drawers rather than its best ones.
What it is not for
Impact guns, full socket sets, or any load approaching the 300 lb the combo is rated for.
The high numbers, and what they cost in documentation
The heaviest-duty figures on this site do not come from the best-documented chests. Here are the models that lead on one spec while leaving others blank.
| Model | Width | Gauge | Per drawer | Total capacity | Volume |
|---|---|---|---|---|---|
| Craftsman V-Series 41 in. | 41 in | 16 ga | 200 lb | 3,000 lb | Not published |
| Montezuma 72 in. 16-drawer | 72.6 in | Not published | 150 lb | 3,300 lb | Not published |
| High Capacity 56 in. 10-drawer | 56 in | Not published | 150 lb | 3,000 lb | 23,583 cu in |
| Homak 72 in. RS Pro hutch | 71.5 in | 16 ga | 100 lb | Not published | 28,702 cu in |
| Montezuma 46 x 24 in. 11-drawer | 46 in | 20 ga | 150 lb | Not published | Not published |
| WEN 52 in. 9-drawer | 52 in | 21 ga | 100 lb | Not published | Not published |
Chests that publish a leading figure on one axis and nothing on another. A blank is an absence from the maker, not from this page.
The Craftsman V-Series row is the strongest set of published numbers on the site: 16 gauge is the thickest steel of any chest here, and 200 lb per drawer pair is double what most of this list manages. It simply does not publish a volume. That is a far better position than a chest that publishes a volume and hides its gauge, because gauge is the number that is hardest to recover later - you can measure a drawer, but you cannot measure the steel without taking something apart.
The five that publish nothing
Five of the 22 publish no gauge, no drawer rating, no capacity and no volume. Not one of those four numbers.
- MUWOOD 72 in. with power strip - a 72-inch, ten-drawer unit with a solid rubberwood top, and the most expensive thing on this list that publishes nothing at all. The power-strip roundup covers the trade the whole category asks for.
- LARBANKE 56 in. combo - an 18-drawer combination set at a 56-inch width, with no published figure of any kind.
- LARBANKE 13-drawer combo - same position, smaller unit.
- BSMTEK 6-drawer and nifoti 4-drawer - two stainless-topped rolling units. The stainless roundup covers what the word is actually attached to on these, which is usually a countertop rather than a carcass.
There is a pattern in that list and it is not a brand pattern - it is a channel one. The chests that publish four numbers are made by companies with a catalogue, a specification sheet and a warranty department behind them. The chests that publish nothing are typically sold through a single marketplace listing, where the specification is whatever fits in the title.
Where you can actually buy each one
| Brand | Where it is sold | Do we earn anything? |
|---|---|---|
| Milwaukee (46 in. chests and cabinets) | Amazon, Home Depot and the Milwaukee dealer network | Yes, on the Amazon listings |
| Craftsman (S1000, S2000, V-Series) | Amazon, Lowe's and Ace | Yes, on the Amazon listings |
| Husky | The Home Depot only - a house brand, no live Amazon listing | No - there is no affiliate route to a Husky chest, and we say so |
| U.S. General and ICON | Harbor Freight only - in-store and harborfreight.com | No - no affiliate program reaches either line |
| Kobalt | Lowe's only - a house brand | No affiliate route |
| Montezuma, WEN, Homak and the marketplace brands | Amazon | Yes, on the Amazon listings |
We say this on every comparison because it changes what our recommendation is worth to you. Where we earn nothing, there is no commercial reason for us to steer you anywhere.
That table matters more in this category than in most, because four of the most-searched names in tool storage - Husky, Kobalt, U.S. General and ICON - cannot be bought through any affiliate link at all. We rank them anyway where their published numbers earn it, which is why Husky sits at the top of the four-number table above and we make nothing from saying so.
How to read these four numbers
If you are using this table to choose rather than to browse, the order to read it in is not left to right.
- Per-drawer rating first. This is the number you meet every day, it is the one that decides whether the deep drawer takes impact sockets, and published guidance is to design to 70-80 percent of it. What a slide rating covers explains why a 100 lb pair is an 80 lb drawer.
- Then gauge. Thinner steel flexes, and flex is what eventually puts a drawer out of alignment. 18 gauge is the practical floor for a chest you load heavily; 24 gauge, as on the Craftsman S1000, tells you the unit is built for hand tools and light duty.
- Then volume, not drawer count. Eight deep drawers and ten shallow ones can hold the same tools, and the eight will take the awkward ones better. Cubic inches is the honest capacity figure and drawer count is a marketing one.
- Total capacity last. It is the figure most likely to be a round number chosen for the listing, and the one you are least likely to approach in a garage.
- Then check the width against your wall. A 56-inch chest needs five feet of clear wall plus the drawer pull-out in front of it, which is the measurement people get wrong. How tool boxes are measured covers what the headline number leaves out.
And if a chest you are considering is not in these tables, the question to ask is not 'is it good' but 'what does its maker publish'. A listing that states a drawer count, a color and a total weight has told you almost nothing about the two things that decide how a chest ages.
The honest verdict
On published documentation, Milwaukee and Craftsman lead this category: between them they hold five of the six fully-documented rows, and they are both buyable online. On raw published numbers, the Craftsman V-Series 41 in. is the strongest chest here at 16 gauge and 200 lb per drawer pair. On documented volume, Husky's 56-inch combo is in a class of its own at 42,876 cu in - and it is the one you cannot buy through this site.
If you want the ranked version of this with verdicts attached rather than a table, the best tool chests is that page. This one exists because sometimes the table is the answer.
Common questions
Which tool chest publishes the most specifications?
Six chests on this site publish all four key figures - steel gauge, per-drawer slide rating, total capacity and storage volume. They are the Husky 56 in. 18-drawer combo, Milwaukee's 46 in. High Capacity cabinet, Milwaukee's 46 in. 8-drawer cabinet, Milwaukee's 46 in. top chest, the Craftsman S2000 41 in. cabinet and the Craftsman S1000 26 in. combo. Of those, the Milwaukee and Craftsman units are buyable online; Husky is a Home Depot house brand.
What is the thickest steel used in a tool chest here?
16 gauge, published by the Craftsman V-Series 41 in. cabinet and the Homak 72 in. RS Pro hutch. The Craftsman V-Series also publishes 200 lb per drawer pair, which is double the typical figure in this category. Eleven of the 22 chests on this site publish no gauge at all.
Which tool chest has the highest drawer rating?
The Craftsman V-Series 41 in. cabinet at 200 lb per drawer pair. Montezuma's 72 in. and 46 in. cabinets and the High Capacity 56 in. publish 150 lb; most of the rest of the category publishes 100 lb, and the Craftsman S1000 publishes 30 lb. Remember published guidance is to load to 70-80 percent of a rated pair.
Why do some chests publish no specifications at all?
Five of the 22 chests here publish no gauge, no drawer rating, no capacity and no volume. The pattern is a channel one rather than a quality one: chests from companies with a catalogue and a specification sheet publish numbers, and chests sold through a single marketplace listing publish whatever fits in the product title. That absence is itself information worth weighing.
Can I buy every chest in this comparison?
No, and that is stated rather than hidden. Husky is a Home Depot house brand, Kobalt is a Lowe's house brand, and U.S. General and ICON are Harbor Freight exclusives - none of them can be bought through any affiliate link, including ours. They are ranked on their published numbers anyway, which is why Husky leads the fully-documented table.
Sources
- Sheet metal gauge chart, standard steel (gauges 14-24)
- Drawer slide load capacity guide - ratings are per pair, design to 70-80%
- The Home Depot - Husky 56 in. 18-drawer combination set (HOTC5618BD1S)
- Milwaukee - 46 in. High Capacity 8-drawer chest specification (48-22-8541)
- Craftsman - S2000 Series 41 in. 10-drawer steel rolling tool cabinet specification (CMST98270RB)
Read next
The best tool chests, ranked on what the maker actually publishes
The flagship roundup: chests and cabinets ranked on published gauge, slide ratings and volume, with three things we would actively skip.
How to choose a tool chest: five numbers, in order
Five published numbers, in the order they should knock options out, with the arithmetic for each shown in full.
Tool box steel gauge, converted into something you can use
Every gauge used in tool storage converted to inches and millimeters, why the numbers run backwards, and what thicker steel actually buys.
Ball-bearing drawer slides, and what a rating covers
How the mechanism works, why ratings are per pair at full extension, what the capacity tiers mean, and the four stages of failure.
How tool boxes are measured, and what the number leaves out
What the width figure includes and excludes, the cubic-inch conversion, and the measurements the listing will never give you.
46-inch tool chests, the size that fits an actual garage
The size that fits a single-car bay with the car in it - and where 18-gauge steel is actually available.
56-inch tool chests, and the five feet of wall they really need
What a 56-inch cabinet really needs in floor space, what the width figure excludes, and the ones worth buying on published specs.
Tool chest vs tool cabinet, and which half to buy first
The terminology settled once, and the reason the cabinet is almost always the half to buy first.
